Technical Parameters:
Controller Parameters
- Working Voltage: 5V~24V DC
- Data Type: SPI
- Working Current: 14mA~20mA
- IC Type: Single-wire RZ RGBW LED driver IC
- Working Temp: -10℃~40℃
- MAX Pixels: 450
- Dimension: 56mm*21mm*12mm (Not including the wires)
Remote Control Parameters：
- Working Voltage: 3V(CR2025)
- Static Current: 1uA
- Transport: 2.4G
- Remote Distance: 30M (Open space)
- Dimension: 103mm*45mm*8.5mm
Note:Restore Factory Settings Plug and unplug the power 5 times consecutively → Each power-on lasts approximately 1–2 seconds and must not exceed 5 seconds (exceeding 5 seconds resets the count) → Each power-off lasts at least 2 seconds → After 5 cycles, the white light flashes 3 times to indicate a successful reset.
Brief:
SP669E SPI RGBW BT LED Controller that supports both App and 2.4G remote control. App features an intuitive visualized UI for real-time lighting effect preview and includes a wide range of dynamic RGB lighting effects as well as independent white
light effects. Combining both colorful and white light modes, it fully meets users’ comprehensive needs for lighting and atmosphere creation.
Features:
- Supports two convenient control methods: App control and 2.4G RF remote control.
- All-new scene-based app UI design with support for scene switching, lighting effects can be previewed in real time for clear and intuitive visibility.
- Built-in rich dynamic effects and music effects for both white and RGB lighting.
- Upgraded custom effects interface with more intuitive operation and support for effect saving.
- Supports personalized favorites, allowing users to create a custom lighting effect list with loop playback and timer settings.
- Supports customizable power-ON/OFF effects and startup state settings.
- Supports channel order calibration, device group management, timer ON/OFF, and auto-reconnect functions.
- Supports OTA updates, ensuring your device stays with the latest features and improvements.
Work With 2.4G Remote Control:
The 2.4G remote control model (RF3) compatible with SP669E: Support one-to-many control, one remote control can control multiple controllers; Support many-to-one control, each controller can bind up to 5 remote controls.
